Equip your kitchen with a powerful 30-inch 585 CFM motor class under-cabinet range hood system designed to pair with 30-inch KitchenAid® Commercial-Style Ranges and Rangetops. A 75,000 BTU rating allows this vent hood to keep up with high-heat cooking on multiple burners. Four fan speeds let you choose the right setting for cooking adventures from simmering to searing.
Specification
| Accessory Relationships | Yes |
| Certifications|Energy Star® Qualified | No |
| Certifications|Kosher Consumer Friendly | No |
| Certifications|Prop 65 | Standard |
| Certifications|UL | Yes |
| Controls|Control Location | Front |
| Controls|Control Type | Push Button |
| Description|Hood Type | Under Cabinet |
| Description|Size (in.) | 30 |
| Carton Depth | 15 inch |
| Carton Height | 27 inch |
| Carton Width | 34 inch |
| Cutout Height (in) | 10 inch |
| Cutout Width (in) | 30 inch |
| Depth | 23 inch |
| Height | 36 inch |
| Width | 30 inch |
| Gross Weight | 49 inch |
| Net Weight | 46.0 inch |
| Dimensions|Canopy Height (IN,inches) | 10.00000 |
| Dimensions|Carton Depth(IN,inches) | 15.0000 |
| Dimensions|Carton Height(IN,inches) | 27.0000 |
| Dimensions|Carton Width(IN,inches) | 34.0000 |
| Dimensions|Cutout Height Min(IN,inches) | 10.0000 |
| Dimensions|Cutout Height(IN,inches) | 10.0000 |
| Dimensions|Cutout Width(IN,inches) | 30.0000 |
| Dimensions|Depth(IN,inches) | 23.0000 |
| Dimensions|Gross Weight(LB,pounds) | 49 |
| Dimensions|Maximum Height(IN,inches) | 36.0000 |
| Dimensions|Net Weight(LB,pounds) | 46 |
| Dimensions|Width(IN,inches) | 30.0000 |
| Electrical|Amps | 3.8 |
| Electrical|Hz | 60 |
| Electrical|Power Cord Included | No |
| Electrical|Volts | 120 |
| Electrical|Watts | 463 |
| Features|Auto On | Yes |
| Features|BTU Threshold | 75 K |
| Features|Damper Included | Yes |
| Features|Lighting Control Type | Push Button |
| Features|Night Light | Yes |
| Features|Night Light Type | LED |
| Features|Number of Night Light Settings | 1 |
| Features|Number of Task Light Settings | 1 |
| Features|Task Light Type | LED |
| Features|Task Lighting | Yes |
| Ventilation System| HVI (CFM HS Horizontal) | 380 |
| Ventilation System| HVI (CFM HS Vertical) | 380 |
| Ventilation System| HVI (Sones HS Horizontal) | 8 |
| Ventilation System| HVI (Sones HS Vertical) | 8 |
| Ventilation System|Auto Function | Auto On |
| Ventilation System|Blower Motor | Blower Motor Included |
| Ventilation System|Blower Type | Centrifugal |
| Ventilation System|Duct Direction | Vertical or Horizontal |
| Ventilation System|Duct Outlet Size (in.) | 3.25 W x 10 H |
| Ventilation System|Duct Type | Rectangular |
| Ventilation System|Exhaust Vent Location | Top |
| Ventilation System|Filters | Removable Stainless Steel Baffle Filters |
| Ventilation System|Maximum Motor Exhaust Rating Cubic Feet per Minute (CFM) | 585 |
| Ventilation System|Number of Vent Speeds | 4 |
| Ventilation System|Sound Max Speed (dB(A) | 66.4 |
| Ventilation System|Sound Max Speed (Sones) | 8.0 |
| Ventilation System|Sound Min Speed (dB(A) | 50.5 |
| Ventilation System|Sound Min Speed (Sones) | 2.00 |
| Ventilation System|Vent Fan Location | Side |
| Ventilation System|Vent Material | Aluminum |
| Ventilation System|Venting | Exterior |
